HomeProducts Direct-driver oilless



Model Motor

Pressure

Cylinder 50Hz 60Hz  Tank N.W. MEAS.
Stroke Speed Displacement Stroke Speed Displacement
kw HP bar psi mm n mm rpm L/min cfm mm rpm L/min cfm L Gal kg Lbs L×W×H(cm)
GPW-MT550-24 0.55 0.75 8 116 63.5 2 12 1450 110  3.9  12 1700 129 4.6  24 6.3  21 46  58×28×65
GPW-MT750-24 0.75 1 8 116 69.7 2 12 1450 133  4.7  12 1700 156 5.5  24 6.3  22 49  58×28×65
GPW-MT550SB 0.55 0.75 8 116 63.5 2 12 1450 110  3.9  12 1700 129 4.6  16 4.2  18 40  54×46×43
GPW-MT750SB 0.75 1 8 116 69.7 2 12 1450 133  4.7  12 1700 156 5.5  16 4.2  19 42  54×46×43
